ETLBox logo Welcome to ETLBox

It's all in the box! Run all your ETL or ELT jobs with this C# class library. Create your own dataflow, where data is send from a source to a target and transformed on its way. Data can be read from or written into various sources.

ETLBox.net

There is a project homepage for ETLBox availabe: etlbox.net contains all the information you need about ETLBox. There is a whole set of introductional articles, examples for Control Flow Tasks, Data Flow Tasks and Logging, and finally a complete API documentation.

See the video

Watch a short video that introduces you into the basic concepts of ETLBox and how to create your own ETL process. See the video on Youtube!

What is ETLBox

ETLBox is a comprehensive C# class library that is able to manage your whole ETL or ELT. You can use it to run some simple (or complex) sql against your database. You can easily manage your database using some easy-to-use and easy-to-understand objects. Or you can create your own dataflow pipeline, where data is send from a source to a target and transformed on its way. All that comes with extended logging capabilites, that allow you to monitor and anlayze your ETL job runs.

Why ETLBox

Perhaps you are looking for an alternative to Sql Server Integrations Services (SSIS). Or you are searching for a framework to define and run ETL jobs with C# code. The goal of ETLBox is to provide an easy-to-use but still powerful library with which you can create complex ETL routines and sophisticated data flows.

Advantages of using ETLBox

Build ETL in C#: Code your ETL with a language fitting your team’s skills and that is coming with a mature toolset

Run locally: Develop and test your ETL code locally on your desktop using your existing development & debugging tools.

Process In-Memory: ETLBox comes with dataflow components that allow in-memory processing which is much faster than storing data on disk and processing later.

Know your errors: When exceptions are raised you get the exact line of code where your ETL stopped, including a hands-on description of the error.

Manage Change: Track you changes with git (or other source controls), code review your etl logic, and use your existing CI/CD processes.

Embedded or standalone: With .NET core and .NET standard, etlbox is a self-deploying toolbox – usable whereever .NET runs. (.NET Standard 2.0 or higher required). Or just include the library as a reference to your existing .NET projects.

Supported sources and destinations

The following table shows which types of sources and destination are supported with the current version of ETLBox

Source or Destination type Supported by ETLBox
Sql Server Full support
Postgres Full support
SQLite Full support
MySql Full support
Files Support for Json and CSV
Supported by CustomSource/CustomDestination

ETLBox capabilities

ETLBox is split into two main components: Data Flow and Control Flow Tasks. Both components will provide customizable logging functionalities.

Control Flow Tasks

Control Flow - overview

Control Flow Tasks gives you control over your database: They allow you to create or delete databases, tables, procedures, schemas, ... or other objects in your database. With these tasks you also can truncate your tables, count rows or execute any sql you like. Anything you can script in sql can be done here - but mostly with only one line of easy-to-read C# code. This improves the readability of your code a lot, and gives you more time to focus on your business logic. But Control Flow tasks are not restricted to databases only: e.g. you can even run an XMLA on your Sql Server Analysis Service.

Data Flow Tasks

Data Flow - overview

Dataflow tasks gives you the ability to create your own pipeline where you can send your data through. Dataflows consists of one or more source element (like CSV files or data derived from a table), some transformations and optionally one or more target. To create your own data flow , you need to accomplish three steps:

  • First you define your dataflow components.
  • Then, you link these components together (each source has an output, each transformation at least one input and one output and each destination has an input).
  • After the linking you just tell your source to start reading the data.

The source will start reading and post its data into the components connected to its output. As soon as a connected component retrieves any data in its input, the component will start with processing the data and then send it further down the line to its connected components. The dataflow will finish when all data from the source(s) are read and received from the destinations.

Of course, all data is processed asynchronously by the components. Each compoment has its own set of buffers, so while the source is still reading data the transformations already can process it and the destinations can start writing the processed information into their target.

Data flow tasks - examples

It's easy to create your own data flow pipeline. This example pipe will transfer data from a MySql database into a Sql Server database and transform the records on the fly.

Just create a source, some transformation and a destination:

var sourceCon = new MySqlConnectionManager("Server=10.37.128.2;Database=ETLBox_ControlFlow;Uid=etlbox;Pwd=etlboxpassword;");
var destCon = new SqlConnectionManager("Data Source=.;Integrated Security=SSPI;Initial Catalog=ETLBox;");

DBSource<MySimpleRow> source = new DBSource<MySimpleRow>(sourceCon, "SourceTable");
RowTransformation<MySimpleRow, MySimpleRow> trans = new RowTransformation<MySimpleRow, MySimpleRow>(
    myRow => {
        myRow.Value += 1;
        return myRow;
    });
DBDestination<MySimpleRow> dest = new DBDestination<MySimpleRow>(destCon, "DestinationTable");

Now link these pipeline elements together.

source.LinkTo(trans);
trans.LinkTo(dest);

Finally, start the dataflow at the source and wait for your destination to rececive all data (and the completion message from the source).

source.Execute();
dest.Wait();

Control Flow - example

The easiest way to connect all your tasks to a database is to store the connection string in the Control Flow object

ControlFlow.CurrentDbConnection = new SqlConnectionManager(new ConnectionString("...connection string..."));

Afer this, you can basically execute any kind of control flow tasks, for instance:

Execute some sql on the DB.

SqlTask.ExecuteNonQuery("Do some sql",$@"EXEC dbo.myProc");

Count rows in a table.

int count = RowCountTask.Count("demo.table1").Value;

Create a table using a TableDefinition object:

CreateTableTask.Create("Table1", new List<TableColumn>() {
    new TableColumn(name:"key",dataType:"INT",allowNulls:false,isPrimaryKey:true, isIdentity:true),
    new TableColumn(name:"value", dataType:"NVARCHAR(100)",allowNulls:true)
});

Logging

Default logging with NLog

By default, ETLBox uses NLog. ETLBox already comes with NLog as dependency. So the needed packages will be retrieved from nuget. In order to have the logging activating, you just have to set up a nlog configuration called nlog.config, and create a target and a logger rule. After adding this, you will already get some logging output.

A simple log configuration could log lik this (add this as nlog.config into your root folder)

<?xml version="1.0" encoding="utf-8"?>
<nlog xmlns="http://www.nlog-project.org/schemas/NLog.xsd"
      xsi:schemaLocation="NLog NLog.xsd"
      xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">
  <rules>
    <logger name="*" minlevel="Debug" writeTo="debugger" />
  </rules>
  <targets>
    <target name="debugger" xsi:type="Debugger" />
  </targets>
</nlog>

If you need additionally informationa about NLog, please see the NLog Project Website

Advanced logging into the database

Additionally to the traditional nlog setup where log information can be send to any target, ETLBox comes with a set of Tasks and a recommended nlog configuration. This will allow you to have a more advanced logging into your database. E.g., you can create log tables and stored procudures useful for logging in SQL with the CreateLogTablesTask.

It will basically create two log tables - the table etl.Log for the "normal" log and a table etl.LoadProcess to store information about your ETL run. Whenever you use a Control Flow or Data Flow task, log information then is written into the etl.Log table. Additionally, you can use tasks like StartLoadProcessTask or EndLoadProcessTask which will write information about the current ETL process into the etl.LoadProcess table.

ETLBox Logviewer

Once you have data in these log tables, you can use the ETLBox LogViewer to easily access and analyze your logs.

Process Overview of ETLBox LogViewer Process Details of ETLBox LogViewer

Getting ETLBox

You can use ETLBox within any .NET or .NET core project that support .NET Standard 2.0.

Adding ETLBox to your project

Variant 1: Nuget

ETLBox is available on nuget. Just add the package to your project via your nuget package manager.

Variant 2: Download the sources

Clone the repository:

git clone https://github.com/roadrunnerlenny/etlbox.git

Then, open the downloaded solution file ETLBox.sln with Visual Studio 2015 or higher. Now you can build the solution, and use it as a reference in your other projects.

Going further

Open Source

Feel free to make changes or to fix bugs. Every particiation in this open source project is appreciated.

Test projects

To dig deeper into it, have a look at the ETLBox tests within the solution. There is a test for (almost) everything that you can do with ETLToolbox.

ETLBox.net

See the ETLBox Project website for introductional articles and examples for Control Flow Tasks, Data Flow Tasks and Logging. There is also a complete API documentation. Enjoy!
